RXM-25 Available Configurations
The RXM-25 can be built with a number of positioner and antenna configurations. All antenna options share high cross-polarization isolation, low sidelobe levels, and are built with a low-weight composite material main reflector suitable for outdoor operation. In cases where no overall system radome will be used, antenna wind loading can be reduced with the addition of a low-loss nose-cone type radome. The available high-torque positioner systems share a set of slip rings designed for high-speed digital signal transmission, can be pressurized (together with the radar transceiver) to operate in harsh outdoor conditions, and are matched to the available antenna size options.
Please select from the following options:
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 1.2 m (4 feet) |
| Radome type | None |
| System height | 2.14 m |
| System diameter | 1.79 m |
| System mass | 208 kg |
|
Scanning Performance
| Positioner torque | 488 Nm (max) |
| Slew velocity | 50°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 60 mph (max.) |
|
Sensing Performance
| Antenna Gain | 38.5 dB |
| Beam width | 1.8° |
Minimum reflectivity
detection (30 km) | 9.7 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 1.2 m (4 feet) |
| Radome type | Nose cone |
| System height | 2.24 m |
| System diameter | 2.00 m |
| System mass | 213 kg |
|
Scanning Performance
| Positioner torque | 488 Nm (max) |
| Slew velocity | 50°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 60 mph (max.) |
|
Sensing Performance
| Antenna Gain | 38.0 dB |
| Beam width | 1.8° |
Minimum reflectivity
detection (30 km) | 10.7 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 1.8 m (6 feet) |
| Radome type | None |
| System height | 2.35 m |
| System diameter | 2.20 m |
| System mass | 236 kg |
|
Scanning Performance
| Positioner torque | 488 Nm (max) |
| Slew velocity | 50°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 60 mph (max.) |
|
Sensing Performance
| Antenna Gain | 42.0 dB |
| Beam width | 1.4° |
Minimum reflectivity
detection (30 km) | 4.9 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 1.8 m (6 feet) |
| Radome type | Nose cone |
| System height | 2.63 m |
| System diameter | 2.78 m |
| System mass | 246 kg |
|
Scanning Performance
| Positioner torque | 488 Nm (max) |
| Slew velocity | 50°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 60 mph (max.) |
|
Sensing Performance
| Antenna Gain | 41.5 dB |
| Beam width | 1.4° |
Minimum reflectivity
detection (30 km) | 5.9 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 1.8 m (6 feet) |
| Radome type | None |
| System height | 2.71 m |
| System diameter | 2.46 m |
| System mass | 576 kg |
|
Scanning Performance
| Positioner torque | 936 Nm (max) |
| Slew velocity | 60°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 80 mph (max.) |
|
Sensing Performance
| Antenna Gain | 42.0 dB |
| Beam width | 1.4° |
Minimum reflectivity
detection (30 km) | 4.9 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 1.8 m (6 feet) |
| Radome type | Nose cone |
| System height | 2.99 m |
| System diameter | 3.02 m |
| System mass | 586 kg |
|
Scanning Performance
| Positioner torque | 936 Nm (max) |
| Slew velocity | 60°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 80 mph (max.) |
|
Sensing Performance
| Antenna Gain | 41.5 dB |
| Beam width | 1.4° |
Minimum reflectivity
detection (30 km) | 5.9 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 2.4 m (8 feet) |
| Radome type | None |
| System height | 2.89 m |
| System diameter | 2.82 m |
| System mass | 615 kg |
|
Scanning Performance
| Positioner torque | 936 Nm (max) |
| Slew velocity | 60°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 60 mph (max.) |
|
Sensing Performance
| Antenna Gain | 45.0 dB |
| Beam width | 1.0° |
Minimum reflectivity
detection (30 km) | 1.8 dBz |
|
Overview
| Antenna type | Front-fed parabolic |
| Primary diameter | 2.4 m (8 feet) |
| Radome type | Nose cone |
| System height | 3.05 m |
| System diameter | 3.14 m |
| System mass | 633 kg |
|
Scanning Performance
| Positioner torque | 936 Nm (max) |
| Slew velocity | 60°/s (max.) |
| Scan acceleration | 60°/s² (max.) | | Wind load | 60 mph (max.) |
|
Sensing Performance
| Antenna Gain | 44.5 dB |
| Beam width | 1.0° |
Minimum reflectivity
detection (30 km) | 2.8 dBz |
|
